Graphene and Carbon Nanotubes
Graphene-based materials are often used in sensors and wearable electronics for their flexibility and excellent conductivity. However, there are a few delicate processes to handle, which present several challenges.
Challenges:
- Graphene layers need to be as thin as possible for optimal flexibility and conductivity.
- Classical electronic depositing methods, including lithography and masking, require a longer preparation time, making them less accessible for low-cost electronics.
- Placing thin layers of graphene onto an object is a very delicate process that needs to be damage-free.
- Often, the deposition requires a special pattern or shape.
Your Advantages of Using Microdispensing at a Glance:
- Ultra-low volume handling to substrates of any type.
- No interaction between the dispenser unit and substrate prevents damage to the surface.
- Lines, curves, and other structures can be printed on-the-fly using the Autodrop system.
- Established in literature as a rapid prototyping process.
Example Applications of Inkjet-based Printing of Graphene and Carbon Nanotubes:
- InkJet-printed supercapacitor electrodes of graphene-carboxymethyl cellulose biocomposite Ink
- Graphene nanoplatlets and graphene oxide to form different functional electronic 3D structures
- Printing chitosan and carboxymethyl cellulose together with graphene structures into different electrodes.
- Printing conductive carbon nanotubes to from conductive structures.
- Print deformable and wearable carbon nanotube microwire-based sensors for monitoring of strain, pressure and torsion using single-walled carbon nanotubes.
- Printing of a polymere/CNT composite to form a gas sensor.
What do our customers say:
At the Graphene Center of Excellence, we have successfully utilized a microdrop technologies printer (MD-P802) for a range of research and development projects involving the deposition of various materials onto diverse substrates. These printers have consistently demonstrated exceptional performance in terms of:
- Accuracy and Precision: The printers have consistently delivered high accuracy and precision in material deposition, enabling us to achieve the desired micro and nano scale features with exceptional repeatability.
- Versatility: The systems have proven highly versatile, accommodating a wide range of materials, including inks and nanoparticles, and enabling printing onto a variety of substrates such as glass, silicon, and flexible polymers.
- User Friendliness: The intuitive software and user friendly interface of the microdrop printers have significantly streamlined our workflow and minimized training requirements for our research team. Furthermore, we have been highly impressed with the after sales service provided by microdrop their technical support team has been readily available to address any questions or concerns, providing timely and effective assistance whenever needed.
